Introduced in 2009, Shacman F2000 series the one of the best seling product. Reliable, rugged and powerful, Shacman F2000 series can tackle any task its owner ask of it.
Shacman F2000 is the first choice for overseas engineering projects. This series platform also has the largest volume in the international market, winning the hearts of its operators.
Platform | Shacman F2000 | |
Drive type | 6X4 | |
Vehicle model | SX5255GJBJR384 | |
Vehicle Weight | GVW:15 tons | |
GCW:35 tons | ||
Frame | 850×300(8+7) | |
Engine | Weichai | Emissions: Euro II to Euro V |
Displacement: 10L – 12L | ||
Power: 300 PS – 420 PS | ||
Torque: 1200 Nm – 2100 Nm | ||
Cummins | Emissions: Euro II to Euro V | |
Displacement: 10L – 12L | ||
Power: 340 PS – 420 PS | ||
Torque: 1200 Nm – 2100 Nm | ||
Transmission | 10JSD180 | |
Clutch | φ430 | |
Steering gear | ZF8098 | |
Axle | Front axle: MAN 9.5 ton | |
Rear axle: MAN 16-ton single or double reduction | ||
Gear ratio: 4.769 – 5.92 | ||
Suspension | Multi-leaf spring front and rear setup | |
Tires | 315 / 80R22.5 | |
12R22.5 | ||
12.00R20 | ||
Fuel tank | 400 – 700 liter aluminum or steel tank | |
Dimensions(LxWxH) | 8200×2490×3300 | |
Volume(m³) | 8-10 | |
Wheelbase | 3775+1400mm | |
Approach/Departure angle(°) | 20/18 | |
Max.gradeability(%) | 34 | |
Cab | Type | Shacman F2000, lengthened flat roof |
Equipments | ◆Rear window ◆Mechanical clerestory ◆Hydraulic suspension of the cab ◆Hydraulic driver seat with seatbelts ◆One sleeping bed ◆Hydraulic reversal ◆Radio with MP3 player |
|
Optional | ● Air-cushioned driver’s seat ●Full vehicle WABCO valve ●Electronic air conditioning with temperature control |
Have more questions? Don’t hesitate to reach out! We’re always here and happy to help.
We have ISO,OTTC,EAC,GCC,CE, third parties’ inspections are all available such SGS, BV ect.
Trucks We have a fixed model for each country, suitable for local use.For trailer,if you have your own design , we can produce according to your specification and drawing.
Under normal circumstances, we ship from Shanghai, Tianjin, Qingdao, Lianyungang ports, you can specify other ports according to your needs.
Accepted Delivery Terms: FOB,CFR,CIF,EXW;Accepted Payment Currency:USD,CNY;Accepted Payment Type: T/T,L/C,Western Union,Cash;Language Spoken:English,Spanish,French
Shacman Truck 12 months unlimited mileage;Trailer warranty 1 year;And we have service outlets in South America, Africa and many other countries.
