The upper body and chassis of the Shacman X3000 cement mixer truck adopt an integrated design, which maximizes the vehicle’s performance and significantly improves the vehicle’s attendance rate. Shacman has established close cooperative relations with more than 120 professional modification companies across the country, including well-known companies such as Sany Heavy Industry, CIMC Vehicles, and Tangshan Yate, and can meet the diverse professional needs of users.
Platform | Shacman F3000 | |
Drive type | 6X4 | |
Vehicle model | SX5255GJBDN384 | |
Vehicle Weight | GVW:15 tons | |
GCW:35 tons | ||
Frame | 850×300(8+7)mm | |
Engine | Weichai | Emissions: Euro II to Euro V |
Displacement: 10L – 12L | ||
Power: 300 PS – 420 PS | ||
Torque: 1200 Nm – 2100 Nm | ||
Cummins | Emissions: Euro II to Euro V | |
Displacement: 10L – 12L | ||
Power: 340 PS – 420 PS | ||
Torque: 1200 Nm – 2100 Nm | ||
Transmission | 10JSD180 | |
Clutch | φ430 | |
Steering gear | ZF8098 | |
Axle | Front axle: MAN 9.5 ton | |
Rear axle: MAN 16 ton single or double reduction | ||
Gear ratio: 4.769 – 5.92 | ||
Suspension | Multi leaf spring front and rear setup | |
Tires | 315 / 80R22.5 | |
12R22.5 | ||
12.00R20 | ||
Fuel tank | 400 – 700 liter aluminum or steel tank | |
Dimensions(LxWxH) | 8200×2490×3300 | |
Volume(m³) | 8-10 | |
Wheelbase | 3775+1400mm | |
Approach/Departure angle(°) | 20/18 | |
Max.gradeability(%) | 34 | |
Cab | Type | Shacman F3000, lengthened flat roof |
Equipments | ◆Rear window ◆Manual sunroof ◆Hydraulic driver seat with seatbelts ◆Hydraulic suspension of cab ◆Electronic air conditioning with temperature control ◆Electric window ◆Radio with MP3 player |
|
Optional | ●Air cushioned drivers seat ●Full vehicle WABCO valve |
