Long lasting: Wuhan steel, Baoshan steel material, different thickness for different parts,wear rib on blades. Service life is 1.5 times than average. Unique structure: Revised logarithmic spiral blades, Special mold cold press molding, to ensure speed of concrete in and out, ensure the uniformity of the concrete. Well-equipped:CNC cutting equipment, Automation Welding System, fixtures, Automatic robot welding production line (on trial), to ensure quality. Patent technology: blade curve, antitorque secondary beam, tank heating equipment etc; High-level configuration: imported hydraulic system from Germany, Italy, America.

Platform	Shacman F3000
Drive type	8×4
Vehicle model	SX5315GSNJU456
Vehicle Weight	GVW：15 tons
	GCW：35 tons
Frame	850×300(8+7)
Engine	Weichai	Emissions: Euro II to Euro V
		Displacement: 10L – 12L
		Power: 300 PS – 420 PS
		Torque: 1200 Nm – 2100 Nm
	Cummins	Emissions: Euro II to Euro V
		Displacement: 10L – 12L
		Power: 340 PS – 420 PS
		Torque: 1200 Nm – 2100 Nm
Transmission	12JSD200T-B+QH70
Clutch	φ430
Steering gear	ZF8098
Axle	Front axle: MAN 9.5 ton
	Rear axle: MAN 16-ton single or double reduction
	Gear ratio: 4.769 – 5.92
Suspension	Multi-leaf spring front and rear setup
Tires	315 / 80R22.5
	12R22.5
	12.00R20
Fuel tank	400 – 700 liter aluminum or steel tank
Dimensions(LxWxH)	10800×2490×3300
Volume(m³)	12-18
Wheelbase	1800+4575+1400mm
Approach/Departure angle(°)	20/12
Max.gradeability(%)	27
Cab	Type	SHACMAN F3000, lengthened flat roof
	Equipments	◆Rear window ◆Manual sunroof ◆Hydraulic driver seat with seatbelts ◆Hydraulic suspension of the cab ◆Electronic air conditioning with temperature control ◆Electric window ◆Radio with MP3 player
	Optional	● Air-cushioned driver’s seat ●Full vehicle WABCO valve
