H3000 Tipper Dump Truck 8X4 380HP/385HP

H3000 Tipper Dump Truck 8X4 380HP/385HP

Need Any Help?

For any further inquiries, please don’t hesitate to get in touch. We’re here and eager to provide any assistance you may need.

Email us

Truck Details

Shacman H3000 8×4 Highway Dump Truck uses a high-quality engine with good power, high economy, and cost savings compared to similar products. Our product adopts noise reduction technology, which has good sealing performance and comfortable driving. It can travel for a long distance, can well meet the transportation needs, and is one of the best choices for the transportation industry.

1. The wide and heightened cab provides comfortable driving and better visibility. 2. Lightweight configuration of the whole vehicle, with lighter overall weight. 3. Strengthen the 435 press-welded bridge, which has a higher carrying capacity than competing similar axles and high reliability. 4. Equipped with two-stage air filter to ensure the quality of intake air. 5. The overall speed ratio meets the needs of national highway transportation, and the fuel saving effect is the best.

Transport type	Highway transport
Logistics type	Ore/sand/gravel/coal
Distance(km)	≤200
Road type	Paved roads
Drive	8×4	8×4
Max weight(t)	≤70	≤70
Max speed	85	75
Loaded speed(km)	45~60	45~60
Vehicle model	SX3315MR306	SX3315MT326C
Engine	WP10.380E22	ISM 385
Emission standard	Euroǁ	Euroǁ
Displacement	9.726L	10.8L
Rated output	247kw	283kw
Max. torque	1250N•m	1835N•m
Transmission	10JSD180+QH50	12JSD180T+QH50
Clutch	430	430
Frame	850×300(8+7)	850×300(8+7)
Front axle	MAN 9.5T	MAN 9.5T
Rear axle	16T MAN double reducion 5.262	16 MAN dote dudion 5.262
Tire	12.00R20	12.00R20
Front Suspension	Multi-leaf springs	Multi-leaf springs
Rear Suspension	Multi-leaf springs	Multi-leaf springs
Fuel	Diesel	Diesel
Capacity of the fuel tank	400L ( Aluminum shell )	400L ( Aluminum shell )
Battery	165Ah	180Ah
Dimensions(L×W×H)	8500x2490x3210	8700x2490x3210
Wheelbase	1800+2975+1400	1800+3175+1400
Truck(L×W×H)	6500x2300x1500	6800x2300x1500
Approach/Departure angle(°)	28/55	28/55
Max.gradeability(%)	25	25

Cab	Type	SHACMAN H3000, mid-lengthened flat roof	MAN H3000, mid-lengthened fiat roof
	Equipments	◆Rear window ◆Automated air conditioning ◆Hydraulic suspension of the cab ◆Hydraulic driver seat with seatbelts ◆One sleeping bed ◆Hydraulic reversal ◆Radio with MP3 player	◆Rear window ◆Automated air conditioning ◆Hydraulic suspension of the cab ◆Hydraulic driver seat with seatbelts ◆One sleeping bed ◆Hydraulic reversal ◆Radio with MP3 player
	Optional	●Full vehicle WABCO valve	●Full vehicle WABCO valve

FAQ

Frequently Asked Questions

Have more questions? Don’t hesitate to reach out! We’re always here and happy to help.

What are the certifications for your products?

We have ISO,OTTC,EAC,GCC,CE, third parties’ inspections are all available such SGS, BV ect.

Do you provide custom made Products service?

Trucks We have a fixed model for each country, suitable for local use.For trailer,if you have your own design , we can produce according to your specification and drawing.

What ports of shipment are there?

Under normal circumstances, we ship from Shanghai, Tianjin, Qingdao, Lianyungang ports, you can specify other ports according to your needs.

what services can we provide?

Accepted Delivery Terms: FOB,CFR,CIF,EXW；Accepted Payment Currency:USD,CNY;Accepted Payment Type: T/T,L/C,Western Union,Cash;Language Spoken:English,Spanish,French

About product warranty?

Shacman Truck 12 months unlimited mileage;Trailer warranty 1 year;And we have service outlets in South America, Africa and many other countries.
