Shacman L3000 lightweight dump truck , equipped with Weichai WP8.240 engine, provides 240 horsepower of powerful power. The dump truck has a wheelbase of 1950+2525+1400mm, and the 10-speed design of the Fast S10MOQ gearbox ensures smooth shifting. The body dimensions are 8.715 meters (length)x 2.55 meters (width)x 3.5 meters (height). The vehicle weighs 12.4 tons, the rated load is 18.405 tons, and the total mass is 31 tons.
Type | Shacman L3000 |
Edition | Standard edition |
Vehicle model | SX11858J501R |
Drive | 4×2 |
Wheelbase (mm) | 5000 |
Suspension | Multi-leaf springs |
Engine | ISDe210 30 |
Horsepower | 210HP |
Emission standard | Euro Ⅲ |
Displacement | 6.23L |
Rated output | 155kW |
Max. torque | 750N.m |
Transmission | 8JS85TM |
Clutch | 430 |
Frame | 870×250(7+4) |
Front axle | 4.8T |
Rear axle | MAN 10T single reduction4.625 |
Tire | 10R22.5 |
Fuel | Diesel |
Fuel tank | 300L (Aluminum shell) |
Battery | 135Ah |
Dimensions(L×W×H) | |
Cab | ◆The L3000 cab without a shroud ◆Water tank protection grid ◆Front fixed rear hydraulic mount ◆Hydraulic main seat ◆Electric window ◆Tail light protection grille |
Optional | ●QD40J power take-off |
Have more questions? Don’t hesitate to reach out! We’re always here and happy to help.
We have ISO,OTTC,EAC,GCC,CE, third parties’ inspections are all available such SGS, BV ect.
Trucks We have a fixed model for each country, suitable for local use.For trailer,if you have your own design , we can produce according to your specification and drawing.
Under normal circumstances, we ship from Shanghai, Tianjin, Qingdao, Lianyungang ports, you can specify other ports according to your needs.
Accepted Delivery Terms: FOB,CFR,CIF,EXW;Accepted Payment Currency:USD,CNY;Accepted Payment Type: T/T,L/C,Western Union,Cash;Language Spoken:English,Spanish,French
Shacman Truck 12 months unlimited mileage;Trailer warranty 1 year;And we have service outlets in South America, Africa and many other countries.
