X3000 6X4 Flatbed Truck

X3000 6X4 Flatbed Truck

Need Any Help?

For any further inquiries, please don’t hesitate to get in touch. We’re here and eager to provide any assistance you may need.

Email us

Truck Details

The Shacman X3000 series truck ‌is a widely used truck series launched by Shaanxi Truckload truck. With its powerful performance and diversified configuration, it can meet the needs of different users.

Engine: Shacman X3000 offers a variety of engine options, including Weichai, Cummins, etc., with a wide range of horsepower ranging from 270 to 500 horsepower to meet different transportation needs. Gearbox: Gearbox types include FASTer 9JS119TB, etc., providing smooth and efficient transmission efficiency. Drive type: Shacman X3000 provides 6X2, 8X2, 8X4 and other driving forms to adapt to different road conditions and load requirements. Load capacity: Rated load from 14.42 tons to 25 tons, the total mass of up to 25 tons, to meet the needs of heavy cargo. Emission standard: Shacman X3000 conforms to national 5 / National 6 emission standards and has superior environmental performance. Body size: The length of the body varies from 9.5m to 9.6m, and the width and height also vary according to the specific configuration to adapt to different transport scenarios. Use: Shacman X3000 is suitable for many uses such as warehouse truck, van truck, rail truck, etc., to meet different logistics needs.

Transport type	Shacman X3000 Flatbed truck
Logistics type	Daily industrial products and food
Distance(km)	≤300km
Road type	Paved roads
Drive	6×4
Max weight(t)	≤35
Crusing speed/Max speed(km/h)	90
Loaded speed(km/h)	50~65
Vehicle model	SX12555R434
Engine	WP10.380E22
Emission standard	Euro Ⅱ
Displacement	9.726L
Rated output	250kW
Max. torque	1400N·m
Transmission	10JSD180
Clutch	430
Frame	850×300(8+5 )
Front axle	MAN 7.5T
Rear axle	13T MAN double reduction 4.769
Tire	12.00R20
Front Suspension	Multi-leaf springs
Rear Suspension	Multi-leaf springs
Fuel	Diesel
Capacity of the fuel tank	400L( Aluminum shell )
Battery	180Ah
Dimensions(L×W×H)	7700×2490×3250
Trunk(L×W×H)	5500×2300×800
Wheelbase	4375+1400
After the suspension	2400
Approach/Departure angle(°)	18/12
Max.grade ability(%)	34

Cab	Type	SHACMAN X3000, mid-lengthened flat roof
	Equipments	◆Rear window ◆Manual sunroof ◆Hydraulic driver seat with seatbelts ◆Hydraulic suspension of the cab ◆Electronic air conditioning with temperature control ◆Electric window ◆Radio with MP3 player
	Optional	●Central locking ● Air-suspended main seat ●Front lamp protector ● Four-point air-suspended cabin ●Desert air filter ● Oil-type air filter ●Electric cab turning ●11.00R20

FAQ

Frequently Asked Questions

Have more questions? Don’t hesitate to reach out! We’re always here and happy to help.

What are the certifications for your products?

We have ISO,OTTC,EAC,GCC,CE, third parties’ inspections are all available such SGS, BV ect.

Do you provide custom made Products service?

Trucks We have a fixed model for each country, suitable for local use.For trailer,if you have your own design , we can produce according to your specification and drawing.

What ports of shipment are there?

Under normal circumstances, we ship from Shanghai, Tianjin, Qingdao, Lianyungang ports, you can specify other ports according to your needs.

what services can we provide?

Accepted Delivery Terms: FOB,CFR,CIF,EXW；Accepted Payment Currency:USD,CNY;Accepted Payment Type: T/T,L/C,Western Union,Cash;Language Spoken:English,Spanish,French

About product warranty?

Shacman Truck 12 months unlimited mileage;Trailer warranty 1 year;And we have service outlets in South America, Africa and many other countries.
