Shacman X3000 8×4 tow truck is an efficient, reliable, and safe special vehicle specially designed to clear vehicles involved in traffic accidents on the road and ensure the smooth flow of roads and traffic safety.
Shacman X3000 8×4 tow truck adopts high-quality body materials and advanced manufacturing technology, and has the advantages of high strength, good stability, wear resistance and corrosion resistance. It also adopts advanced electronic control systems, hydraulic systems and mechanical systems to assist in the handling of road traffic accidents in an efficient and automatic manner, improve the efficiency of accident handling, and reduce the impact on road traffic.
Shacman X3000 8×4 tow truck is fully functional and equipped with various towing equipment, such as lifting cranes, trailers, carts, shears, cutters, electric winches, etc., which can quickly and efficiently handle various types of traffic accident vehicles on the road. In addition, the Shacman X3000 is also equipped with advanced communication equipment, high-definition monitoring systems and GPS positioning systems, which can report accident information in a timely manner, facilitate dispatch and command, and ensure the smooth handling of accidents.
Shacman X3000 8×4 tow truck plays an important role in ensuring road traffic safety. In traffic-intensive areas such as coastal areas and highways, the use of Shacman X3000 tow trucks can effectively reduce traffic congestion and traffic safety incidents caused by road accidents. In special environments, such as rain, snow, fog, night and other bad weather conditions, Shacman X3000 tow trucks can also play an important role in ensuring smooth roads and traffic safety.
Shacman X3000 8×4 tow trucks are not only widely used in China, but also exported overseas and have been highly praised by overseas users. It not only represents the high-level manufacturing technology of China’s automobile industry, but also demonstrates the quality and reputation of Made in China.
At the same time, the XCMG QZZ26T50D is equipped with many high-end configurations and equipment, including electric winches, steerable folding booms, multiple safety protection systems, etc., which makes it more versatile and safe in rescue and towing tasks, and can effectively improve work efficiency and success rate. Contribution.
| Model |
Shacman X3000 Rescue truck |
| Drive type |
8×4 |
| Engine |
Brand |
WEICHAI |
| Model |
WP10.400E22 |
| Power/(kw/HP) |
280kW / 400Hp |
| Maximum torque / (N.M)/rpm |
2060 N·M |
| Displacement/(L) |
11.596 L |
| Emission standard |
Euro II |
| Gear box |
Brand |
FAST |
| Model |
12JSD200T-B+QH50 |
| Clutch |
Type |
φ430 Diaphragm spring clutch |
| Cooling |
Type |
Domestic heat sink |
| Air inlet |
Type |
Ordinary air filter |
| Brakes |
Type |
Drum brake |
| Service brake |
Double circuit air brake |
| Park brake |
Rear wheel spring brake |
| Auxiliary brake |
WEVB engine exhaust brake |
| Steering |
Type |
ZF8098 technology, circulating ball steering machine |
| Chassis |
Type |
Parallel trapezoidal frame with variable section |
| Dimensions/(mm) |
850×300(8+7) |
| Suspension |
Front |
Multi-layered leaf springs with 4 Main springs+4 U Bolts |
| Rear |
Multi-layered leaf springs with 4 Main springs+4 U Bolts |
| Axles |
Brand |
HANDE |
| Front axle |
9.5T front axle MAN technology |
| Rear axle |
16T MAN Double Reduction Drive axle with inter helix differential and differential lock, bridge speed ratio: 5.262 |
| Tires |
Type |
12.00R20 |
| Fuel tank |
Tank capacity/(L) |
300L Aluminum tank |
| Electrics |
Type |
24V |
| Battery |
165Ah Maintenance-free battery |
| Cab |
Type |
SHACMAN X3000 Medium-length flat cab |
| Equipment |
Hydraulic main seat, four-point hydraulic suspension cab, ordinary rearview mirror, electronically controlled automatic constant temperature air conditioner, electric window shaker, 165Ah maintenance-free Battery, SHACMAN logo, full English logo. |
| Crane information |
XCGM QZZ260T50D joint top, inlet valve, two-section six-sided boom, 25 tons of three-section bracket, split carriage (carriage electroplating), two-side linkage operation device, two ten-ton hydraulic winch, 45 meters steel wire rope, diameter of 18MM, with four sets of steel forks, a set of tow fork, a set of steel plate lug tow fork, a set of tire holding device, a long row of engineering alarm lights, One set of auxiliary lights, one set of auxiliary gas pipe assembly, two binding chains, three wireless remote control operations of the rear bracket arm, and the rest are standard. |
