The Shacman 8×4 enhanced version is equipped with the transmission leaf spring suspension to improve the convenience of transmission maintenance, improve parts reliability and reduce maintenance costs. Cooling steel pipe is equipped, the oil temperature of the steering system is reduced, and the component failure rate is effectively reduced. Weichai WEVB exhaust brake system reduces the wear of tires, brake pads and the cost of vehicle use while ensuring safety. The load-carrying capacity of the rear leaf spring of the four U-bolts rear suspension is upgraded. The thickness of the leaf spring is upgraded from (8*22mm+4*25mm) to 12*25mm, and the stiffness is upgraded by 25%. Wheel rim has been reinforced, whose thickness increased from 14mm to 16mm and steel ring from 8.5 to 9.0. Φ120 bore steering gear, the steering assist capacity is increased by 24% The ground clearance is increased up to 636mm, and the thickness of the bottom protector is increased from 3mm to 6mm, which can meet the requirements of customers. The taillight is equipped with a protector to improve the adaptability of complex working conditions, which reduced the risk of the taillight from being damaged.. Matching 9.5 tons of front axle, thickness of front suspension plate spring is 18mm, high stiffness and strong carrying capacity. Three-layer beam for Shacman 8×4 dump truck, the bearing capacity is greatly improved and the bending strength is high. The use of flat tank and optimal placement further improves the ground clearance with better trafficability. A variety of lifting cylinders are available (domestic, DeppKaler, Hyva), lifting capacity up to 100T, lifting time between 14-45 seconds. The front lifting mechanism has the advantages of high efficiency, simple structure, great lifting stability and large lifting capacity.

Type	SHACMAN X3000
Edition	Super edition
Vehicle model	SX33186V306C
Drive	8X4
Wheelbase (mm)	1800+2975+1400
Suspension	Multi-leaf springs
Engine	WP12.430E201
Horsepower	430HP
Emission standard	Euro Ⅱ
Displacement	10.8L
Rated output	309kW
Max. torque	2000N.m
Transmission	12JSD200TA-B-QH50+FHB400
Clutch	430
Frame	850×300（8+7+8）
Front axle	MAN 9.5T
Rear axle	16T MAN two-stage widened bridge 4.769
Tire	12.00R24
Fuel	Diesel
Fuel tank	360L （Aluminum shell）
Battery	180Ah
Inner dimension of loading space(mm)	7300X2300X1500
Material thickness of loading(mm)	Bottom12,Side10
Lifting mode	Multistage front lifting hydraulic system
Cab	◆The SHACMAN X3000 mid-length flat-top cab does not have a roof shroud ◆Automated air conditioning ◆Four-point hydraulic mounting ◆ Air-cushioned driver’s seat ◆Water tank protection grid ◆Electric window
Optional	315/80R22.5
